Digital Printer for Paperboard(boxi-800-A3 )

Model number

BOXI-800

Print head confiquration

HP A3 print head*1

Resolution

1200*1200dpi/1200*600dpi/1200*400dpi/1200*300dpi

Ink type

Water-based ink

Ink tank capacity

CMYK

1000ml/color

Print range

Nozzle print width 297mm, unlimited length

Printing material range

The maximum width of the material is 1000mm, the height is450mm, and the length is not limited

Applicable material paper

corrugated paper, card paper, kraft paper and other inkabsorption paper

Print thickness

450mm

Interface type

Network cable

Voltage

AC220V，50HZ-60HZ

Rated power

800W

Print method

Color only

Print mode

CMYK

Printing speed

High quality, variable printing

10-20m/min

Standard production mode

30m/min

High speed production mode

40m/min

Print software

Boxi Print Tools

Graphic format

PDF/TIF/PG

Printer dimension

L*W*H

1516mm*1605mm*1595mm

N.W.

370KG

Packing size

L*W*H

1810mm*1760mm*1620mm

G.W.

580KG

Working environment

Temperature

20℃-30℃

Humidity

40%-80%(no gel)

Noise

Below 75dB
